| 订货号：SXYSJ000 | 品牌：Panasonic/松下 | 货号：4KS250DAA |
| 型号：4KS250DAA | 适用范围：空调，冷水，除湿 | 功率：1.50kw |
| 重量：18kg | 结构类型：转子式 | 类型：生产用制冷设备 |
| 排量类型：定排量压缩机 | 是否跨境货源：否 |
压缩机产品特征
系列 | R | P | K | V |
特征 | 体积小巧，高效 | 具有多种冷煤和电源 | 有R22、R407C、R410A | 具有R22、R410A |
适用机型 | 0.75HP空调器 | 1HP空调器 | 1.5HP空调器 | 2HP—2.5HP空调器 |
R系列性能参数及外形尺寸
型号 | 制冷量 | 输入功率 | 能效比 | 电源规格 | 电容 | ||
W | BTU/H | W |
|
|
| ||
国内/欧洲 | 2R10B22***SA | 1595/1605 | 5440/5475 | 540/590 | 2.954/2.720 | 220V/240V/50HZ | 15UF/370V |
2R11B3R22***SD | 1745 | 5955 | 585 | 2.983 | 220V/50HZ | 12.5UF/460V | |
2R12B225CSD | 1895 | 6465 | 660 | 2.871 | 220V/50HZ | 20UF/400V | |
2R12B225CSG | 1895 | 6465 | 660 | 2.871 | 220V/50HZ | 20UF/400V | |
2R13C22***SC | 2070 | 7065 | 715 | 2.895 | 220V/50HZ | 20UF/370V | |
2R13C225BSA | 2020/2035 | 6890/6945 | 690/745 | 2.928/2.732 | 220V/240V/50HZ | 15UF/400V | |
北美 | 2R7S3R126A6A | 1475 | 5035 | 468 | 3.152 | 115V/60HZ | 35UF/230V |
2R8S126A6J | 1640 | 5595 | 520 | 3.154 | 115V/60HZ | 35UF/230V | |
2R9S126A6H | 1880 | 6415 | 595 | 3.16 | 115V/60HZ | 35UF/250V | |
2R9S126A6J | 1880 | 6415 | 595 | 3.16 | 115V/60HZ | 35UF/250V | |
2R10S236A6E | 1940 | 6620 | 615 | 3.155 | 208V/230V/60HZ | 15UF/370V | |
2R11S3R126A6B | 2100 | 7165 | 665 | 3.158 | 115V/60HZ | 35UF/230V | |
2R12S126A6J | 2330 | 7950 | 740 | 3.149 | 115V/60HZ | 35UF/250V | |
美洲 | 2R10S236A6E | 1940 | 6620 | 615 | 3.155 | 208V/230V/60HZ | 15UF/370V |
2R11S236A6H | 2100 | 7165 | 665 | 3.158 | 208V/230V/60HZ | 15UF/370V | |
2R11S236A6J | 2085 | 7115 | 665 | 3.135 | 208V/230V/60HZ | 15UF/370V | |
2R12S3R236A6B | 2325 | 7935 | 737 | 3.155 | 208V/230V/60HZ | 15UF/370V | |
型号 | 冷煤类型 | 壳体 | 储液器 | 储液器直径(C) | 机角度 | 认证 | |
安装高度(A) | 安装高度(A) | ||||||
| mm | mm | mm | 0 |
| ||
国内/欧洲 | 2R10B22***SA | R22 | 210 | 205 | φ30 | R/30° | CCC/TUV |
2R11B3R22***SD | R22 | 210 | 205 | φ30 | R/105° | CCC/TUV | |
2R12B225CSD | R22 | 210 | 268 | φ54.4 | R/60° | CCC | |
2R12B225CSG | R22 | 210 | 205 | φ30 | R/30° | CCC | |
2R13C22***SC | R22 | 220 | 273 | φ75 | R/60° | CCC | |
2R13C225BSA | R22 | 210 | 260 | φ64 | R/30° | CCC | |
北美 | 2R7S3R126A6A | R22 | 210 | 205 | φ30 | R/90° | UL/CSA |
2R8S126A6J | R22 | 210 | 205 | φ30 | R/30° | UL/CSA | |
2R9S126A6H | R22 | 215 | 205 | φ30 | R/90° | UL/CSA | |
2R9S126A6J | R22 | 215 | 205 | φ30 | R/15° | UL/CSA | |
2R10S236A6E | R22 | 215 | 266 | φ50 | R/90° | UL/CSA | |
2R11S3R126A6B | R22 | 215 | 205 | φ30 | R/90° | UL/CSA | |
2R12S126A6J | R22 | 220 | 205 | φ40 | R/90° | UL/CSA | |
美洲 | 2R10S236A6E | R22 | 215 | 266 | φ50 | R/90° | UL/CSA |
2R11S236A6H | R22 | 215 | 205 | φ40 | R/30° | UL/CSA | |
2R11S236A6J | R22 | 215 | 205 | φ50 | R/90° | UL/CSA | |
2R12S3R236A6B | R22 | 220 | 205 | φ40 | R/90° | UL/CSA | |
